Fanless X86 Industrial Mini PC Wide Temp Support Multi-Core CPU Up to 32GB DDR4 Rich Serial Dual LAN IO Ports

ECS-ADN351 is a fanless X86 industrial mini PC built for harsh industrial environments. It supports multiple low-power multi-core Intel CPUs, up to 32GB DDR4 memory, dual gigabit Ethernet, 6 serial ports, 8 GPIO, HDMI+VGA dual display and complete M.2 expansion for Wi-Fi/4G/5G. With passive heat dissipation, it delivers stable wide-temperature operation from -20℃ to +60℃ (-40℃~+70℃ optional). It runs Windows and Linux systems, ideal for factory automation, machine vision, IoT gateways and transportation monitoring. Its vibration-resistant, dustproof fanless design ensures long-term reliable operation on-site.

    Contact us Download
    product details

    description1

    Technical Information

    Processor Intel N95, 4C4T, up to 3.4 GHz, 16 EU iGPU, TDP: 15W
    Intel N97, 4C4T, up to 3.6 GHz, 24 EU iGPU, TDP: 12W
    Intel N100, 4C4T, up to 3.4 GHz, 24 EU iGPU, TDP: 6W
    Intel N200, 4C4T, up to 3.7 GHz, 32 EU iGPU, TDP: 6W
    Intel Core i3 N300, 8C8T, up to 3.8 GHz, 32 EU iGPU, TDP: 7W
    Intel Core i3 N305, 8C8T, up to 3.8 GHz, 32 EU iGPU, TDP: 15W
    Intel Atom X7425E, 4 cores and 4 processors, up to 3.4 GHz, 24 EU iGPU, TDP: 12W
    Intel N150, 4C4T, up to 3.6 GHz, 24 EU iGPU, TDP: 6W
    Intel N250, 4C4T, up to 3.8 GHz, 32 EU iGPU, TDP: 6W
    Intel Core i3 N350, 8C8T, up to 3.9 GHz, 32 EU iGPU, TDP: 7W
    Intel Core i3 N355, 8C8T, up to 3.9 GHz, 32 EU iGPU, TDP: 15W
    Intel Atom X7211RE, 2C2T, up to 3.2 GHz, 16 EU iGPU, TDP: 6W
    Intel Atom X7213RE, 2C2T, up to 3.4 GHz, 16 EU iGPU, TDP: 9W
    Intel Atom X7433RE, 4C4T, up to 3.4 GHz, 32 EU iGPU, TDP: 9W
    Intel Atom X7835RE, 8C8T, up to 3.6 GHz, 32 EU iGPU, TDP: 12W
    Memory Supports one SO-DIMM DDR4 memory module, up to 32GB, with frequencies of 2133/2666/3200MHz.
    Graphics processing One HDMI port with a maximum resolution of 3840x2160 @ 60Hz.
    1 VGA port with a maximum resolution of 1920x1080 @ 60Hz
    Network card Supports 2 REALTEK 8111H 10/100/1000Mbit Ethernet
    Storage Supports one SATA 3.0 interface and one M.2 SSD (M-Key 2280 SSD PCIe x1/NGFF).
    mPCIe Supports one M.2 WIFI (E-Key 2230 PCIe x1 & USB 2.0)
    Supports one M.2 4G/5G port (B-Key 3042/3052 USB 2.0)
    USB Supports 4 USB 3.0 ports and 2 USB 2.0 ports.
    Serial port 4 RS232 (3-wire), 2 RS232 (3-wire) / RS422 / RS485
    IO Supports 8 GPIOs and 1 SIM card slot (optional).
    Sound card ALC662/ALC897 High-Fidelity Sound Card (Line-Out, MIC-in)
    Power supply +12V to +19V voltage, +12V is recommended. Power on (default), trigger power on (optional).
    Adapter 60W or above
    Temperature Operating temperature: -20°C to +60°C (optional: -40°C to +70°C)
    Size 205 mm (L) x 140 mm (W) x 57 mm (H) (Overall dimensions, excluding wall mount and external interface)
    Heat dissipation Fanless design
    Operating system Windows 10, Windows 11, Linux
    Weight 1.46 kg (bare machine), 2.55 kg (including packaging)
    Color The entire unit is blue, with black front and rear panels.
